Canadian 7kw 8kw 9kw best on grid inverter with battery backup
Canadian 7kw 8kw 9kw best on grid inverter with battery backup
Item NO.:
CSI-7K-9K-S22002-EDShipping Port:
Shanghai/NingboLead Time：
15days（1—10pieces）；To be negotiated（10pType:
Grid TiePayment:
30% deposit, balance paid before shippingCertificate:
VDE.INMETROWarranty:
5yearsCanadian 7kw 8kw 9kw best on grid inverter with battery backup
This type of inverter:
Fully stocked,full models, full sizes.
Three-DayExpress Shipping
First-hand supplyultra-low price
Top 10 Tier 1 agents in the industry
| SYSTEM TECHNICAL DATA | |||
| MODEL NAME | CSI-7K-S22002-ED | CSI-8K-S22002-ED | CSI-9K-S22002-ED |
| DC INPUT | |||
| Max. PV Power (W) | 9100 | 10400 | 11700 |
| Max. DC Input Voltage (V) | 600 | 600 | 600 |
| Start-up DC Input Voltage (V) | 120 | 120 | 120 |
| MPPT Operating Voltage Range (V) | 100 - 500 | 100 - 500 | 100 - 500 |
| Rated Input Voltage (V) | 360 | 360 | 360 |
| Max. Input Current (A) | 12.5 / 25 | 12.5 /25 | 12.5 / 25 |
| Max. Short-Circuit Current (A) | 15 / 30 | 15 / 30 | 15 / 30 |
| Number of MPP Trackers | 2 | 2 | 2 |
| Number of DC Inputs | 1//2 | 1//2 | 1//2 |
| AC OUTPUT | |||
| Rated Output Power (W) | 7000 | 8000 | 9000 |
| Max. Output Power (W) | 7700 | 8000 | 9000 |
| AC Grid Connection Type | L / N / PE | ||
| AC Nominal Votage And Range (V) | 220 / 230 / 240 (180 ~ 280) | ||
| AC Nominal Frequency And Range (Hz) | 50 / 60 (± 5) | ||
| Max. Output Current (A) | 35 | 36.4 | 40.9 |
| Power Factor (@Rated Output Power) | > 0.99 | ||
| Displacement Power Factor | 0.8 leading to 0.8 lagging | ||
| Total Harmonic Distortion (THDi) | < 3 % | ||
| EFFICIENCY | |||
| Max. Efficiency | 98.10% | 98.10% | 98.10% |
| European Efficiency | 97.50% | 97.50% | 97.50% |
| MPPT Efficiency | 99.90% | 99.90% | 99.90% |
| SAFETY &PROTECTION | |||
| DC SPD | Type II | ||
| DC Switch | Integrated | ||
| Anti-Islanding Protection | Integrated | ||
| DC Reverse-Polarity Protection | Integrated | ||
| Insulation Monitoring | Integrated | ||
| AC Over Voltage Protection | Integrated | ||
| AC Over Current Protection | Integrated | ||
| AC Short-Circuit Protection | Integrated | ||
| Residual Current Protection | Integrated | ||
| Overvoltage Class | II (DC), III (AC) | ||
| GENERAL PARAMETERS | |||
| Dimensions (W*H*D, mm) | 399 * 583 * 192 | ||
| Net Weight (kg) | 19.3 | ||
| Installation Method | Wall - mounted | ||
| DC Connection Type | MC4 / H4 | ||
| AC Connection Type | Connector | ||
| Communication Interfaces | RS485 / WiFi | ||
| Display | LED Indicator | ||
| Cooling | Natural Convection | ||
| Protection Degree | IP65 | ||
| Operating Ambient Temperature Range (℃) | - 25 ~ 60 °C (> 45 °C, derating operation) | ||
| Relative Humidity (Non-Condensing) | 0 % ~ 100 % | ||
| Max. Operating Altitude (m) | 4000 m (> 3000 m, derating operation) | ||
| Acoustic Noise Emission Level (dBA) | < 25 | ||
| Topology | Transformerless | ||
| Night Power Consumption (W) | < 1 | ||
| Safety and EMC | IEC 62109-1/2, IEC 61000-6-1, IEC 61000-6-3 | ||
| Grid Connection Standard | ABNT NBR 16149/16150:2013, IEC61727, IEC62116 | ||
