Payment:
allWarranty:
10 yearsCycle life:
25±2℃,0.5C/0.5C,EOL70%≥6000| Rack-Mounted Battery(HV) | |||||
| Model | BOS-G Pro | ||||
| Main Parameter | |||||
| Cell Chemistry | LiFePO₄ | ||||
| Module Energy(kWh) | 5.12 | ||||
| Module Nominal Voltage(V) | 51.2 | ||||
| Module Capacity(Ah) | 100 | ||||
| Battery Module Number | BOS-G25 Pro | BOS-G40 Pro | BOS-G60 Pro | BOS-G85 Pro | |
| Battery Module Qty In Series(Optional) | 5(Min) | 8 | 12 | 17(Max) | |
| System Nominal Voltage(V) | 256 | 409.6 | 614.4 | 870.4 | |
| System Operating Voltage(V) | 220~292 | 352~467.2 | 528~700.8 | 748~992.8 | |
| System Energy(kWh) | 25.6 | 40.96 | 61.44 | 87.04 | |
| System Usable Energy(kWh) | 23.04 | 36.86 | 55.3 | 78.33 | |
| 25.6 | 40.96 | 55.3 | 87.04 | ||
| Charge/Discharge² Current(A) |
Recommend | 50 | |||
| Nominal | 100 | ||||
| Peak Discharge(2mins,25℃) | 125 | ||||
| Working Temperature(℃) | Charge:0~55/Discharge:-20~55 | ||||
| Status Indicator | Yellow:Battery High Voltage Power On Red:Battery System Alarm | ||||
| Communication Port | CAN2.0/RS485 | ||||
| Humidity | 5%～85%RH | ||||
| Altitude | ≤3000m | ||||
| IP Rating of Enclosure | IP20 | ||||
| Dimension(W×D×H,mm) | 530×602×1629 | 530×602×2219 | 1060×602×1629 | ||
| Weight Approximate(kg) | 290 | 428 | 622 | 883 | |
| Installation Location | Rack Mounting | ||||
| Storage Temperature(℃) | 0~35 | ||||
| Recommend Depth of Discharge | 90% | ||||
| cycle Life | 25±2℃,0.5C/0.5C,EOL70%≥6000 | ||||
| Warranty | 10 years | ||||
| rtification | UN38.3/CE/CE-EMC/IEC62040/CEC/VDE | ||||
| 1.DC Usable Energy,test conditions:90%DOD,0.3Ccharge&discharge at 25℃.System usable energy may vary due to system configuration parameters. | |||||
| 2.The current is affected by temperature and SOC. | |||||
| 3.The warranty is due whichever reached first of warranty period or life cycle power. | |||||
| 4.Made in China. | |||||
