Products

lead acid battery charging voltage 12v 100ah

residential and commercial mounting lead acid battery charging voltage 12v 100ah

Warranty:
3YEARS
Chargeable:
Yes
Application:
Solar Energy Storage Systems
Brand Name:
Sunrover
Certification:
CE and TUV
Model Number:
12V 100AH
Place of Origin:
Anhui, China
Weight:
30.8kg
The charging ratio:
98%
The discharge rate:
98%
model type:
12v 100ah
max discahrge current:
30I 10A(3 min)
max charge current:
≤0.25C 10
cover material:
ABS
recommended using temperature:
15℃-25℃
charge voltage:
Float Charge:13.4V-13.7V;Average Charge:14.1V-14.4V
Material:
lead-acid

Supply Ability
10000 Piece/Pieces per Week

Packaging Details
Package: Standard export package, Composite material box
Port
Shanghai/Ningbo/Qingdao

  • Payment:

    T/T / L/C / Paypal / Western Union
  • Warranty:

    3 year
  • Cycle life:

    100%DOD,572 times;50%DOD,1422 times;30%DOD 2218times

residential and commercial mounting lead acid battery charging voltage 12v 100ah

Technology Data
Model Type
12V100AH
Reted Voltage
12V
Capacity(10hr,1.80V/Cell)
100Ah
Weight
30.8kg
Max.Discharge Current
30I 10A(3min)
Max.Charge Current
≤0.25C 10
Self-Discharge(25℃)
﹤3% month
Recommended Using Temperature
15℃-25℃
Cover Material
ABS
Using Temperature
Discharge:-45℃-50℃;Charge:-20℃-45℃;Storage:-30℃-40℃
Charge Voltage(25℃)
Float Charge:13.4V-13.7V;Average Charge:14.1V-14.4V
Temperature Compensation Coefficient(25℃)
Float Temperature Compensation Coefficient:-3mV/Cell℃
Equalization Temperature Compensation Coefficient:-4mV/Cell℃
Cycle Life
100%DOD,572 times;50%DOD,1422 times;30%DOD 2218times
Capacity Affected by Temperature
105%@40℃;85%@0℃;60%@-20℃


Lead acid batterylead-acid battery gel battery 12v 100ah
