Type:
Solis-(215-255)K-EHV-5GMax.Power:
255KWOutput Voltage:
920VPayment:
ALLCertificate:
CEWarranty:
10 years
| Models | 255K |
| Input DC | |
| Max. input voltage | 1500 V |
| Rated voltage | 1080 V |
| Start-up voltage | 500 V |
| MPPT voltage range | 480 - 1500 V |
| Max. input current | 14 × 26 A |
| Max. short circuit current | 14 × 40 A |
| MPPT number / Max. input strings number | 14 / 28 |
| Output AC | |
| Output power | 255 kVA@30°C / 235 kVA@40°C / 220 kVA@50°C |
| Rated grid voltage | 3/PE, 800 V |
| Grid voltage range | 640 - 920 V |
| Rated grid frequency | 50 Hz / 60 Hz |
| Max. output current | 184.0 A |
| Power factor | ＞0.99 (0.8 leading - 0.8 lagging) |
| THDi | ＜3% |
| Efficiency | |
| Max. efficiency | 99.00% |
| EU efficiency | 98.70% |
| Protection | |
| DC reverse-polarity protection | Yes |
| Short circuit protection | Yes |
| Output over current protection | Yes |
| Surge protection | DC Type II / AC Type II |
| Grid monitoring | Yes |
| Anti-islanding protection | Yes |
| Temperature protection | Yes |
| Strings monitoring | Yes |
| I/V Curve scanning | Yes |
| Night time SVG function | Yes |
| Integrated PID recovery | Yes |
| Integrated DC switch | Yes |
| General Data | |
| Dimensions (W × H × D) | 1125 × 770 × 384 mm |
| Weight | 113 kg |
| Topology | Transformerless |
| Self-consumption (night) | < 2 W |
| Operating ambient temperature range | -30 ~ +60°C |
| Relative humidity | 0 - 100% |
| Ingress protection | IP66 |
| Cooling concept | Intelligent fan-cooling |
| Max. operation altitude | 4000 m |
| Grid connection standard | EN50549, G99, AS4777.2, VDE0126, IEC61727, VDE4110, CEA 2019 |
| Safety / EMC standard | IEC/EN 62109-1/-2, IEC/EN 61000-6-2/-4 |
| Features | |
| DC connection | MC4 connector |
| AC connection | OT terminal (max. 300 mm²) |
| Display | LCD |
| Communication | RS485, Optional: PLC |
Efficient Safe Smart Economic
